| 型号 | 外部尺寸（mm） | 工作温度（℃） | 频率范围 | PDF下载 |
| EUAB | 1.2x1.0x0.3mm | -20°C+70°C -30°C+85°C | 26MHz~96MHz | PDF下载 |
| NAOD - 32.768K | 7.0x5.0x1.4mm | -20°C+70°C | 32.768KHz | PDF下载 |
| NAOL | 2.5x2.0x0.95mm | -0°C+70°C -40°C+85°C | 4MHz~125MHz | PDF下载 |
| NXC-63-APA-GLASS | 6.0x3.5x1.2mm | 10°C+60°C -20°C+70°C | 13MHz~125MHz | PDF下载 |
| NXD | 7.0x5.0x1.2mm | -10°C+60°C -20°C+70°C | 6MHz~125MHz | PDF下载 |
| NXC | 6.0x3.5x1.2mm | -10°C+60°C -20°C+70°C | 10MHz~125MHz | PDF下载 |
| NXH-APA-GLASS | 5.0×3.2×1.1mm | -10°C+60°C -20°C+70°C | 13MHz~54MHz | PDF下载 |
| NXH | 5.0x3.2x0.75mm | -10°C+60°C -20°C+70°C | 10MHz~125MHz | PDF下载 |
| NXK-AP4-GLASS | 3.2x2.5x1.0mm | -10°C+60°C -20°C+70°C | 12MHz~40MHz | PDF下载 |
| NXK | 3.2x2.5x0.75mm | -10°C+60°C -20°C+70°C | 12MHz~156.25MHz | PDF下载 |
| NXL | 2.5×2.0×0.55mm | -10°C+60°C -20°C+70°C | 12MHz~50MHz | PDF下载 |
| NXN | 2.0x1.6x0.5mm | -10°C+60°C -20°C+70°C | 20MHz~50MHz | PDF下载 |
| NXR | 1.6×1.2×0.45mm | -10°C+60°C -20°C+70°C | 24MHz~54MHz | PDF下载 |
| CXAF-751 | 7.0x5.0x1.1mm | -40°C+85°C -40°C+125°C -55°C+125°C | 6MHz~133MHz | PDF下载 |
| CXAF-631 | 6.0x3.5x1.1mm | -40°C+85°C -40°C+125°C -55°C+125°C | 8MHz~133MHz | PDF下载 |
| CXAF-531 | 5.0x3.2x0.8mm | -40°C+85°C -40°C+125°C -55°C+125°C | 8MHz~133MHz | PDF下载 |
| CXAF-421 | 4.0x2.5x0.8mm | -40°C+85°C -40°C+125°C -55°C+125°C | 12MHz~52MHz | PDF下载 |
| CXAF-321 | 3.2x2.5x0.75mm | -40°C+85°C -40°C+125°C -55°C+125°C | 8MHz~150MHz | PDF下载 |
| CXAF-221 | 2.5×2.0×0.65mm | -40°C+85°C -40°C+125°C -55°C+125°C | 12MHz~54MHz | PDF下载 |
| CXAF-211 | 2.0x1.6x0.5mm | -40°C+85°C -40°C+125°C -55°C+125°C | 16MHz~96MHz | PDF下载 |
