爱普生MA-306同系列晶振型号有:
产品代号 | 型号 | 频率 | 工作温度 | 负载电容PF | 精度PF |
Q22MA30610004 | MA-306 | 18.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610006 | MA-306 | 18.432000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610007 | MA-306 | 18.432000MHZ | 20°C+70°C | 15 | 50 |
Q22MA30610009 | MA-306 | 18.432000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610010 | MA-306 | 18.432000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610015 | MA-306 | 19.200000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610018 | MA-306 | 19.660800MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610019 | MA-306 | 19.660800MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610022 | MA-306 | 20.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610023 | MA-306 | 20.000000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610026 | MA-306 | 20.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610027 | MA-306 | 20.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610028 | MA-306 | 20.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610036 | MA-306 | 20.480000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610037 | MA-306 | 20.480000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610047 | MA-306 | 22.118400MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610048 | MA-306 | 22.118400MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610050 | MA-306 | 22.222200MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610051 | MA-306 | 22.579200MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610053 | MA-306 | 24.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610054 | MA-306 | 24.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610062 | MA-306 | 24.576000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610063 | MA-306 | 24.576000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610068 | MA-306 | 25.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610071 | MA-306 | 25.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610072 | MA-306 | 25.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610075 | MA-306 | 25.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610079 | MA-306 | 25.175000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610083 | MA-306 | 25.804800MHZ | 20°C+70°C | 22 | 50 |
Q22MA30610085 | MA-306 | 26.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610090 | MA-306 | 27.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610092 | MA-306 | 27.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610093 | MA-306 | 27.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610094 | MA-306 | 27.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610099 | MA-306 | 28.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610104 | MA-306 | 28.322000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610110 | MA-306 | 28.444000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610114 | MA-306 | 28.636360MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610119 | MA-306 | 29.491000MHZ | 20°C+70°C | 22 | 50 |
Q22MA30610120 | MA-306 | 29.491200MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610121 | MA-306 | 29.491200MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610122 | MA-306 | 29.491200MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610124 | MA-306 | 29.491200MHZ | 20°C+70°C | 7 | 50 |
Q22MA30610127 | MA-306 | 30.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610128 | MA-306 | 30.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610136 | MA-306 | 31.948800MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610139 | MA-306 | 32.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610141 | MA-306 | 32.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610142 | MA-306 | 32.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610159 | MA-306 | 32.768000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610160 | MA-306 | 32.768000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610163 | MA-306 | 33.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610165 | MA-306 | 33.000000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610167 | MA-306 | 33.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610170 | MA-306 | 33.000000MHZ | 20°C+70°C | 9.5 | 50 |
Q22MA30610171 | MA-306 | 33.330000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610173 | MA-306 | 33.330000MHZ | 20°C+70°C | 9.1 | 50 |
Q22MA30610176 | MA-306 | 33.333300MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610191 | MA-306 | 36.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610192 | MA-306 | 36.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610195 | MA-306 | 36.864000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610197 | MA-306 | 36.864000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610198 | MA-306 | 36.864000MHZ | 20°C+70°C | 7 | 50 |
Q22MA30610209 | MA-306 | 38.847000MHZ | 20°C+70°C | 7.7 | 50 |
Q22MA30610216 | MA-306 | 39.780000MHZ | 20°C+70°C | 7.2 | 50 |
Q22MA30610220 | MA-306 | 40.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610222 | MA-306 | 40.000000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610224 | MA-306 | 40.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610226 | MA-306 | 40.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610228 | MA-306 | 40.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610229 | MA-306 | 40.000000MHZ | 20°C+70°C | 30 | 50 |
Q22MA30610237 | MA-306 | 24.576000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610238 | MA-306 | 25.000000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610241 | MA-306 | 32.768000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610252 | MA-306 | 20.000000MHZ | 20°C+70°C | 22 | 50 |
Q22MA30610254 | MA-306 | 24.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610255 | MA-306 | 24.576000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610263 | MA-306 | 33.330000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610264 | MA-306 | 27.033000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610266 | MA-306 | 32.560000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610268 | MA-306 | 30.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610269 | MA-306 | 25.000000MHZ | 20°C+70°C | 8.5 | 50 |
Q22MA30610270 | MA-306 | 40.960000MHZ | 20°C+70°C | 6 | 50 |
Q22MA30610276 | MA-306 | 28.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610278 | MA-306 | 32.768000MHZ | 20°C+70°C | 7.5 | 50 |
Q22MA30610279 | MA-306 | 25.000000MHZ | 20°C+70°C | 22 | 50 |
Q22MA30610286 | MA-306 | 31.250000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610287 | MA-306 | 24.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610289 | MA-306 | 20.000000MHZ | 20°C+70°C | 12.5 | 50 |
Q22MA30610292 | MA-306 | 24.576000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610297 | MA-306 | 33.333000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610304 | MA-306 | 38.825000MHZ | 20°C+70°C | 22 | 50 |
Q22MA30610311 | MA-306 | 20.875000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610312 | MA-306 | 36.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610315 | MA-306 | 33.280000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610329 | MA-306 | 14.318180MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610330 | MA-306 | 14.318180MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610336 | MA-306 | 19.660800MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610340 | MA-306 | 17.734470MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610341 | MA-306 | 19.660800MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610347 | MA-306 | 20.300000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610348 | MA-306 | 33.333300MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610349 | MA-306 | 24.000000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610352 | MA-306 | 31.104000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610356 | MA-306 | 29.491200MHZ | 20°C+70°C | 10 | 50 |
Q22MA30610357 | MA-306 | 27.000000MHZ | 20°C+70°C | 12 | 50 |
Q22MA30610359 | MA-306 | 20.000000MHZ | 20°C+70°C | 7.9 | 50 |
Q22MA30610360 | MA-306 | 20.480000MHZ | 20°C+70°C | 7.8 | 50 |
Q22MA30610363 | MA-306 | 20.736000MHZ | 20°C+70°C | 15 | 50 |
Q22MA30610364 | MA-306 | 24.576000MHZ | 20°C+70°C | 27 | 50 |
Q22MA30610368 | MA-306 | 22.579200MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610369 | MA-306 | 28.636360MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610371 | MA-306 | 33.330000MHZ | 20°C+70°C | 12.5 | 50 |
Q22MA30610374 | MA-306 | 14.318180MHZ | 20°C+70°C | 20 | 50 |
Q22MA30610375 | MA-306 | 31.104000MHZ | 20°C+70°C | 7.5 | 50 |
Q22MA30610376 | MA-306 | 28.704000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30610379 | MA-306 | 20.000000MHZ | 20°C+70°C | 7 | 50 |
Q22MA30610380 | MA-306 | 26.562500MHZ | 20°C+70°C | 18 | 50 |
Q22MA30610383 | MA-306 | 26.000000MHZ | 20°C+70°C | 10 | 50 |
Q22MA30620027 | MA-306 | 20.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620028 | MA-306 | 20.000000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30620048 | MA-306 | 22.118400MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620053 | MA-306 | 24.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30620054 | MA-306 | 24.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620062 | MA-306 | 24.576000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620063 | MA-306 | 24.576000MHZ | 20°C+70°C | 20 | 50 |
Q22MA30620071 | MA-306 | 25.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30620072 | MA-306 | 25.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620114 | MA-306 | 28.636360MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620121 | MA-306 | 29.491200MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620141 | MA-306 | 32.000000MHZ | 20°C+70°C | 16 | 50 |
Q22MA30620142 | MA-306 | 32.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620193 | MA-306 | 36.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620226 | MA-306 | 40.000000MHZ | 20°C+70°C | 18 | 50 |
Q22MA30620382 | MA-306 | 19.531250MHZ | 20°C+70°C | 18 | 50 |
爱普生(中国)有限公司成立于1998年,总部设在北京,负责统括爱普生在中国的投资和业务拓展。2004年5月,爱普生(中国)有限公司经中国商务部批准,成为中国首家获得“地区总部”资格认定的外商独资企业。目前,爱普生在华累计投资已超过8.22亿美元(约合50亿元人民币),共有14家制造、销售及服务等机构,员工逾18,000人。
爱普生在中国开展的业务主要有打印机、扫描仪、投影机等信息关联产品业务,电子元器件业务以及工业自动化设备业务。其产品以卓越的品质和节能环保的特点,赢得了中国消费者的厚爱。立足于中国市场,爱普生始终本着“挑战与创新”理念,不断将一系列先进技术及应用方案引入中国,从而使中国消费者能够与世界同步,享受创新科技带来的完美体验。爱普生不断贡献于中国的环保和教育事业,作为一名优秀的中国企业公民而倍感自豪。企业官网请访问:http://www.xtal.cc
