| 型号 | 外部尺寸（mm） | 工作温度（℃） | 频率范围 | PDF下载 |
| DSX211SH | 2.0×1.6×0.45mm | -30°C+85°C | 24MHz ~ 50MHz | PDF下载 |
| DSX1612S | 1.6×1.2×0.35mm | -30°C+85°C | 24MHz ~ 54MHz | PDF下载 |
| NT3225SA | 3.2×2.5×1.0mm | -30°C+85°C | 10MHz~40MHz | PDF下载 |
| NT2520SB | 2.5×2.0×0.9mm | -30°C+85°C | 10MHz~52MHz | PDF下载 |
| NT2016SA | 2.0x1.6x0.8mm | -30°C+85°C | 10MHz~52MHz | PDF下载 |
| NZ3225SH | 3.2×2.5×0.9mm | -10 °C+60 °C -10 °C+70 °C -40 °C+85 °C -40 °C+105 °C -40 °C+125 °C | 1.5MHz~80MHz | PDF下载 |
| NZ2520SB | 2.5×2.0×0.9mm | -40°C+85°C -20 °C+70 °C | 1.5MHz~80MHz | PDF下载 |
| NX3225GA | 3.2×2.5×0.75mm | -40°C+85°C | 9.840MHz~50MHz | PDF下载 |
| NX3225SA | 3.2×2.5×0.55mm | -40°C+85°C -20°C+75°C | 12MHz~150MHz | PDF下载 |
| NX2520SA | 2.5×2.0×0.50mm | -40°C+85°C -20°C+75°C | 16MHz~80MHz | PDF下载 |
| NX2016SA | 2.0×1.6×0.45mm | -40°C+85°C -10°C+75°C | 16MHz~80MHz | PDF下载 |
| NX2012SA | 2.0×1.2×0.55mm | -40°C+85°C | 32.768KHz | PDF下载 |
| SG7050VAN | 5.0x7.0x1.4mm | B: -20°C+70°C G: -40°C+85°C | 73.5MHz~700MHz | PDF下载 |
| SG5032VAN | 5.0x3.2x1.0mm | B: -20°C+70°C G: -40°C+85°C | 73.5MHz~700MHz | PDF下载 |
| VG-4231CA | 7.0×5.0×1.4mm | G：-40°C+85°C J：-20 °C+70 °C | 1MHz ~ 80MHz | PDF下载 |
| VG-4231CB | 5.0×3.2×1.2 mm | G：-40°C+85°C J：-20 °C+70 °C | 1MHz ~ 81MHz | PDF下载 |
| VG2520CAN | 2.5×2.0×0.7 mm | -40°C+85°C, | 30.72MHz , 61.44MHz | PDF下载 |
| TG-5006CE | 3.2x2.5x0.9mm | -30°C+85°C | 13MHz ~ 40MHz | PDF下载 |
| TG-5006CG | 2.5x2.0x0.8mm | -30°C+85°C | 13MHz ~ 52MHz | PDF下载 |
| TG-5006CJ | 2.0x1.6x0.73mm | -30°C +85°C | 13.000MHz to 52.000MHz | PDF下载 |
