| 料号 | 型号 | 频率 | 最低温度 | 最高温度 | 精度 | 电压 |
| KC5032Z16.0000C1GX00 | KC5032Z | 16MHz | -40 | 85 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C14Y00 | KC5032Z | 24MHz | -40 | 105 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C15Y00 | KC5032Z | 24MHz | -40 | 105 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C16Y00 | KC5032Z | 24MHz | -40 | 105 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1GY00 | KC5032Z | 24MHz | -40 | 85 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1HY00 | KC5032Z | 24MHz | -40 | 85 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1JY00 | KC5032Z | 24MHz | -40 | 85 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1KY00 | KC5032Z | 24MHz | -40 | 85 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1LY00 | KC5032Z | 24MHz | -40 | 85 | ±15ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1SY00 | KC5032Z | 24MHz | -10 | 70 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1UY00 | KC5032Z | 24MHz | -10 | 70 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1WY00 | KC5032Z | 24MHz | -10 | 70 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1XY00 | KC5032Z | 24MHz | -40 | 125 | ±100ppm | 1.8V,2.5V,3.3V |
| KC5032Z24.0000C1ZY00 | KC5032Z | 24MHz | -40 | 125 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C14Y00 | KC5032Z | 25MHz | -40 | 105 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C15Y00 | KC5032Z | 25MHz | -40 | 105 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C16Y00 | KC5032Z | 25MHz | -40 | 105 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1GY00 | KC5032Z | 25MHz | -40 | 85 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1HY00 | KC5032Z | 25MHz | -40 | 85 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1JY00 | KC5032Z | 25MHz | -40 | 85 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1KY00 | KC5032Z | 25MHz | -40 | 85 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1LY00 | KC5032Z | 25MHz | -40 | 85 | ±15ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1SY00 | KC5032Z | 25MHz | -10 | 70 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1UY00 | KC5032Z | 25MHz | -10 | 70 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1WY00 | KC5032Z | 25MHz | -10 | 70 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1XY00 | KC5032Z | 25MHz | -40 | 125 | ±100ppm | 1.8V,2.5V,3.3V |
| KC5032Z25.0000C1ZY00 | KC5032Z | 25MHz | -40 | 125 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C14Y00 | KC5032Z | 50MHz | -40 | 105 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C15Y00 | KC5032Z | 50MHz | -40 | 105 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C16Y00 | KC5032Z | 50MHz | -40 | 105 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1GY00 | KC5032Z | 50MHz | -40 | 85 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1HY00 | KC5032Z | 50MHz | -40 | 85 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1JY00 | KC5032Z | 50MHz | -40 | 85 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1KY00 | KC5032Z | 50MHz | -40 | 85 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1LY00 | KC5032Z | 50MHz | -40 | 85 | ±15ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1SY00 | KC5032Z | 50MHz | -10 | 70 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1UY00 | KC5032Z | 50MHz | -10 | 70 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1WY00 | KC5032Z | 50MHz | -10 | 70 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1XY00 | KC5032Z | 50MHz | -40 | 125 | ±100ppm | 1.8V,2.5V,3.3V |
| KC5032Z50.0000C1ZY00 | KC5032Z | 50MHz | -40 | 125 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C14Y00 | KC5032Z | 60MHz | -40 | 105 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C15Y00 | KC5032Z | 60MHz | -40 | 105 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C16Y00 | KC5032Z | 60MHz | -40 | 105 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1GY00 | KC5032Z | 60MHz | -40 | 85 | ±50ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1HY00 | KC5032Z | 60MHz | -40 | 85 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1JY00 | KC5032Z | 60MHz | -40 | 85 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1KY00 | KC5032Z | 60MHz | -40 | 85 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1LY00 | KC5032Z | 60MHz | -40 | 85 | ±15ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1SY00 | KC5032Z | 60MHz | -10 | 70 | ±30ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1UY00 | KC5032Z | 60MHz | -10 | 70 | ±25ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1WY00 | KC5032Z | 60MHz | -10 | 70 | ±20ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1XY00 | KC5032Z | 60MHz | -40 | 125 | ±100ppm | 1.8V,2.5V,3.3V |
| KC5032Z60.0000C1ZY00 | KC5032Z | 60MHz | -40 | 125 | ±50ppm | 1.8V,2.5V,3.3V |
京瓷晶振,全称日本KYOCERA京瓷晶振株式会社成立于1959年由稻盛和夫创办,是一家有着悠久发展历史的知名品牌晶振公司,该公司专注于研发生产石英晶体,有源晶振,温补晶振,差分晶振,压控晶振等元件,是业内领先的制造商之一,京瓷晶振始终如一地开发和制造晶体振荡器和晶体振荡器等产品,这些产品应用了人造石英的栽培特性,同时京瓷晶振向全球市场供应大量水晶产品,为即将到来的智能物联网时代的发展做出贡献。官网请访问http://www.xtal.cc
