50MHz晶振,S23305T-50.000-X-R,安碁AKER晶振,3.3V,50PPM,2520晶振

当前位置:首页 » 加科电子产品中心 » 晶振规格书 » 50MHz晶振,S23305T-50.000-X-R,安碁AKER晶振,3.3V,50PPM,2520晶振

prevnext

查看全部大图

50MHz晶振,S23305T-50.000-X-R,安碁AKER晶振,3.3V,50PPM,2520晶振

产品分类：晶振规格书

订购热线：0755-33533774

跟此产品相关的产品

: 24MHz晶振,AKER安碁晶振,S133025T-24.000-X-R,2016封装,3.3V,25PPM

: 20MHz车载晶振,C3E-20.000-8-3050-X1-R,AKER安碁晶振,3225晶振,8PF,50PPM

: 25MHz晶振,C2E-25.000-10-3030-X-R,AKER安碁晶振,2520晶振,10PF,30PPM

产品详情

S218025T-24.000-R	24MHz	1.8V	±25ppm	-20°C ~ 70°C
S2M05T-24.000-R	24MHz	1.62V ~ 3.63V	±50ppm	-20°C ~ 70°C
S23305T-50.000-R	50MHz	3.3V	±50ppm	-20°C ~ 70°C
S233025T-25.000-R	25MHz	3.3V	±25ppm	-20°C ~ 70°C
S23305T-26.000-R	26MHz	3.3V	±50ppm	-20°C ~ 70°C
S23305T-50.000-X-R	50MHz	3.3V	±50ppm	-40°C ~ 85°C
S2M025T-25.000-X-R	25MHz	1.62V ~ 3.63V	±25ppm	-40°C ~ 85°C
S2M025T-24.000-X-R	24MHz	1.62V ~ 3.63V	±25ppm	-40°C ~ 85°C
S23305-25.000-X-R	25MHz	3.3V	±50ppm	-40°C ~ 85°C
S23305T-25.000-X-R	25MHz	3.3V	±50ppm	-40°C ~ 85°C
S233025T-25.000-X-R	25MHz	3.3V	±25ppm	-40°C ~ 85°C

2520 差分.jpg

S2A33025-25.000-P-X-M	25MHz	3.3V	±25ppm	-40°C ~ 85°C
S2A33025-100.000-P-X-M	100MHz	3.3V	±25ppm	-40°C ~ 85°C
S2A33025-125.000-P-X-M	125MHz	3.3V	±25ppm	-40°C ~ 85°C
S2A33025-156.250-P-X-M	156.25MHz	3.3V	±25ppm	-40°C ~ 85°C
S2A33025-155.520-P-X-M	155.52MHz	3.3V	±25ppm	-40°C ~ 85°C

3225 有源温补.jpg

S3M025T-8.000-R	8MHz	1.62V ~ 3.63V	±25ppm	-20°C ~ 70°C
S3M05T-8.000-R	8MHz	1.62V ~ 3.63V	±50ppm	-20°C ~ 70°C
S333025T-25.000-X-R	25MHz	3.3V	±25ppm	-40°C ~ 85°C
S325025T-25.000-X-R	25MHz	2.5V	±25ppm	-40°C ~ 85°C
S31805T-50.000-R	50MHz	1.8V	±50ppm	-20°C ~ 70°C
S33305T-50.000-R	50MHz	3.3V	±50ppm	-20°C ~ 70°C
S333025T-8.000-R	8MHz	3.3V	±25ppm	-20°C ~ 70°C
S333025T-50.000-X-R	50MHz	3.3V	±25ppm	-40°C ~ 85°C
S33305-50.000-X-R	50MHz	3.3V	±50ppm	-40°C ~ 85°C


S3A3305-125.000-L-X2-R	125MHz	3.3V	±50ppm	-40°C ~ 105°C
S3A2505-100.000-L-X1-R	100MHz	2.5V	±50ppm	-40°C ~ 125°C
S3A3305-156.250-P-X2-R	156.25MHz	3.3V	±50ppm	-40°C ~ 105°C
S3A3305-125.000-P-X2-R	125MHz	3.3V	±50ppm	-40°C ~ 105°C
S3A3305-100.000-P-X2-R	100MHz	3.3V	±50ppm	-40°C ~ 105°C

5032 有源.jpg

S53305-125.000-X-R	125MHz	3.3V	±25ppm	-40°C ~ 85°C
S533025T-25.000-R	25MHz	3.3V	±25ppm	-20°C ~ 70°C
S533025T-25.000-X-R	25MHz	3.3V	±25ppm	-40°C ~ 85°C
S53305T-125.000-X-R	125MHz	3.3V	±50ppm	-40°C ~ 85°C
S53303-1.000-R	1MHz	3.3V	±30ppm	-40°C ~ 85°C
S525025-24.000-R	24MHz	2.5V	±25ppm	-40°C ~ 85°C
S53305-20.000-X1-R	20MHz	3.3V	±50ppm	-40°C ~ 85°C
S53305-66.666-X-LE-2.0-R	66.666MHz	3.3V	±50ppm	-40°C ~ 85°C
S53310-26.000-LE-4.0-R	26MHz	3.3V	±100ppm	0°C ~ 70°C
S5M03-50.000-X-R	50MHz	1.62V ~ 3.63V	±30ppm	-40°C ~ 85°C
S53303T-24.000-X-R	24MHz	3.3V	±30ppm	-40°C ~ 85°C
S53305T-10.000-X-R	10MHz	3.3V	±50ppm	-40°C ~ 85°C
S53305T-14.31818-X-R	14.31818MHz	3.3V	±50ppm	-40°C ~ 85°C
S53305-56.000-X-LE0.5-R	56MHz	3.3V	±50ppm	-40°C ~ 85°C
S533025-24.000-X-LE2.00-R	24MHz	3.3V	±25ppm	-40°C ~ 85°C

5032 差分.jpg

S5A3303-156.250-H-X-R	156.25MHz	3.3V	±30ppm	-40°C ~ 85°C
S5A3305-156.250-L-X-R	156.25MHz	3.3V	±50ppm	-40°C ~ 85°C
S5A33025-156.250-P-R	156.25MHz	3.3V	±25ppm	0°C ~ 70°C
S5A25025-25.000-L-X-R	25MHz	2.5V	±25ppm	-40°C ~ 85°C
S5A3303-27.000-H-X-R	27MHz	3.3V	±30ppm	-40°C ~ 85°C

7050 OSC 12M.jpg

S73305T-25.000-R	25MHz	3.3V	±50ppm	-20°C ~ 70°C
S73305T-25.000-X-15-R	25MHz	3.3V	±50ppm	-40°C ~ 85°C
S733025T-25.000-15-R	25MHz	3.3V	±25ppm	-20°C ~ 70°C
S73305T-32.000-R	32MHz	3.3V	±50ppm	-20°C ~ 70°C
S73305-20.000-X-15-R	20MHz	3.3V	±50ppm	-40°C ~ 85°C
S73305T-11.2896-X-30-R	11.2896MHz	3.3V	±50ppm	-40°C ~ 85°C
S73305T-50.000-X-R	50MHz	3.3V	±50ppm	-40°C ~ 85°C
S73310-60.000-X-15-R	60MHz	3.3V	±100ppm	-40°C ~ 85°C
S73305T-125.000-R	125MHz	3.3V	±50ppm	-20°C ~ 70°C
S73305T-40.000-X-R	40MHz	3.3V	±50ppm	-40°C ~ 85°C
S73305-16.000-15-R	16MHz	3.3V	±50ppm	-20°C ~ 70°C
S733025-74.929-X-R	74.929MHz	3.3V	±25ppm	-40°C ~ 85°C
S73303T-65.536-X-R	65.536MHz	3.3V	±30ppm	-40°C ~ 85°C
S73305-20.000-X-LE2.0-R	20MHz	3.3V	±50ppm	-40°C ~ 85°C
S733025-33.000-X-LE-0.5-R	33MHz	3.3V	±25ppm	-40°C ~ 85°C
S72505T-25.000-R	25MHz	3.3V	±50ppm	-40°C ~ 85°C
S733025-14.7456-X-R	14.7456MHz	3.3V	±25ppm	-40°C ~ 85°C
S733305-12.000-X-LE2.0-R	12MHz	3.3V	±50ppm	-40°C ~ 85°C
S73310-66.000-LE1.5-R	66MHz	3.3V	±50ppm	-40°C ~ 85°C


S7A3305-125.000-P-R	125MHz	3.3V	±50ppm	0°C ~ 70°C
S7A3303-25.000-P-R	25MHz	3.3V	±30ppm	0°C ~ 70°C
S7A33025-100.000-H-X-R	100MHz	3.3V	±25ppm	-40°C ~ 85°C
S7A33025-156.250-P-X-R	156.25MHz	3.3V	±25ppm	-40°C ~ 85°C

AKER晶振分类

差分晶振

详细信息

精选产品

AKER CRYSTAL

AKER oscillator

AKER oscillator

AKER oscillator

S3A3305-125.000-L-X2-R

了解详情

爆款产品

热销品牌

查看更多品牌

AKER晶振简介

安碁科技成立于公元1990年,主要从事晶振产品的研发,制造及销售,拥有深厚的研发技术底蕴,为晶振之专业制造公司,深耕台湾,布局全球,在美国与中国大陆均设有据点,提供客户最及时的服务朝客户导向目标迈进,科技不断的进步,安碁科技亦不断提升技术服务,透过与客户紧密的互动,了解客户需求,提供客户全方位的技术支持─Total Solution,贯彻安棋诚信为首,专业化客户服务及质量优先的理念,公司愿景-追求卓越不断创新与客户一同成长,成为客户在频率控制元件领域的最佳伙伴,AKER进口晶振现货商品的产品介绍和图片,请浏览我们的网站www.smdxtal.com/。
