20MHz温补晶振,TCXO晶振,3.3V,±500ppb,B31-020.0M,

当前位置:首页 » 加科电子产品中心 » 晶振规格书 » 20MHz温补晶振,TCXO晶振,3.3V,±500ppb,B31-020.0M,

prevnext

查看全部大图

20MHz温补晶振,TCXO晶振,3.3V,±500ppb,B31-020.0M,

产品分类：晶振规格书

订购热线：0755-33533774

跟此产品相关的产品

产品详情

型号	频率范围	电压	频率稳定性	工作温度
B31-020.0M	20 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-028.8M	28.8 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-040.0M	40 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-030.0M	30 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-026.0M	26 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-038.4M	38.4 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-050.0M	50 MHz	3.3V	±500ppb	-30°C ~ 85°C
B31-025.0M	25 MHz	3.3V	±500ppb	-30°C ~ 85°C
XK372-022.5792M	22.5792 MHz	3.3V	±50ppm	-40°C ~ 85°C
XK372-30.72M	30.72 MHz	3.3V	±50ppm	-40°C ~ 85°C
D32G-019.2M	19.2 MHz	3.3V	±500ppb	-30°C ~ 85°C
XK372-0050.0M	50 MHz	3.3V	±50ppm	-40°C ~ 85°C
D32G-026.0M	26 MHz	3.3V	±500ppb	-30°C ~ 85°C
XK372-025.0M	25 MHz	3.3V	±50ppm	-40°C ~ 85°C
D32G-016.368M	16.368 MHz	3.3V	±500ppb	-30°C ~ 85°C
XK372-40.96M	40.96 MHz	3.3V	±50ppm	-40°C ~ 85°C
XK372-38.88M	38.88 MHz	3.3V	±50ppm	-40°C ~ 85°C
XK372-048.0M	48 MHz	3.3V	±50ppm	-40°C ~ 85°C
XK372-024.0M	24 MHz	3.3V	±50ppm	-40°C ~ 85°C
XK372-020.0M	20 MHz	3.3V	±50ppm	-40°C ~ 85°C
XK372-24.576M	24.576 MHz	3.3V	±50ppm	-40°C ~ 85°C
D32G-016.368M-T	16.368 MHz	3.3V	±500ppb	-30°C ~ 85°C
D32G-019.2M-T	19.2 MHz	3.3V	±500ppb	-30°C ~ 85°C
D32G-026.0M-T	26 MHz	3.3V	±500ppb	-30°C ~ 85°C
M602-049.152M	49.152 MHz	3.3V	±280ppb	-40°C ~ 85°C
M100F-019.2M	19.2 MHz	3.3V	±100ppb	-0°C ~ 70°C
V7223T-098.304M	98.304 MHz	3.3V	-	-40°C ~ 85°C
M200F-020.0M	20 MHz	3.3V	±200ppb	-40°C ~ 85°C
D53G-026.0M	26 MHz	3.3V	±500ppb	-30°C ~ 85°C
V7223T-125.0M	125 MHz	3.3V	-	-40°C ~ 85°C
M602-040.0M	40 MHz	3.3V	±280ppb	-40°C ~ 85°C
M200F-040.0M	40 MHz	3.3V	±200ppb	-40°C ~ 85°C
V7223T-100.0M	100 MHz	3.3V	-	-40°C ~ 85°C
M100F-012.8M	12.8 MHz	3.3V	±100ppb	-0°C ~ 70°C
M100V-019.2M	19.2 MHz	3.3V	±100ppb	-0°C ~ 70°C
V7223T-049.152M	49.152 MHz	3.3V	-	-40°C ~ 85°C
M200F-024.576M	24.576 MHz	3.3V	±200ppb	-40°C ~ 85°C
M100V-012.8M	12.8 MHz	3.3V	±100ppb	-0°C ~ 70°C
V7223T-080.0M	80 MHz	3.3V	-	-40°C ~ 85°C
ML602-024.576M	24.576 MHz	3.3V	±140ppb	-40°C ~ 85°C
V7223T-074.1758M	74.1758 MHz	3.3V	-	-40°C ~ 85°C
V7223T-122.88M	122.88 MHz	3.3V	-	-40°C ~ 85°C
V7223T-102.4M	102.4 MHz	3.3V	-	-40°C ~ 85°C
V7223T-155.52M	155.52 MHz	3.3V	-	-40°C ~ 85°C
D53G-020.0M	20 MHz	3.3V	±500ppb	-30°C ~ 85°C
V7223T-050.0M	50 MHz	3.3V	-	-40°C ~ 85°C
M100V-020.0M	20 MHz	3.3V	±100ppb	-0°C ~ 70°C
V7223T-081.92M	81.92 MHz	3.3V	-	-40°C ~ 85°C
M100F-010.0M	10 MHz	3.3V	±100ppb	-0°C ~ 70°C
M100F-020.0M	20 MHz	3.3V	±100ppb	-0°C ~ 70°C
V7223T-061.44M	61.44 MHz	3.3V	-	-40°C ~ 85°C
M100V-010.0M	10 MHz	3.3V	±100ppb	-0°C ~ 70°C
M602-025.0M	25 MHz	3.3V	±280ppb	-40°C ~ 85°C
ML602-020.0M	20 MHz	3.3V	±140ppb	-40°C ~ 85°C
M200F-010.0M	10 MHz	3.3V	±200ppb	-40°C ~ 85°C
V7223T-148.5M	148 MHz	3.3V	-	-40°C ~ 85°C
V7223T-077.76M	77.76 MHz	3.3V	-	-40°C ~ 85°C
D53G-020.0M-T	20 MHz	3.3V	±500ppb	-30°C ~ 85°C
V7223T-156.25M	156.25 MHz	3.3V	-	-40°C ~ 85°C
M605T-030.0M	30 MHz	3.3V	±280ppb	-40°C ~ 85°C
D53G-026.0M-T	26 MHz	3.3V	±500ppb	-30°C ~ 85°C
V7223T-074.25M	74.25 MHz	3.3V	-	-40°C ~ 85°C
T602-024.576M	24.576 MHz	3.3V	±280ppb	-40°C ~ 85°C
T200F-012.8M	12.8 MHz	3.3V	±200ppb	-40°C ~ 85°C
TB602-038.88M	38.88 MHz	3.3V	±280ppb	-40°C ~ 85°C
T604-038.88M	38.88 MHz	3.3V	±280ppb	-40°C ~ 85°C
DV75C-040.0M	40 MHz	3.3V	±280ppb	-40°C ~ 85°C
LM113-288.0M	288 MHz	3.3V	±25ppm	-0°C ~ 70°C
DV75D-020.0M	20 MHz	3.3V	±1ppm	-40°C ~ 85°C
TL602-024.576M	24.576 MHz	3.3V	±140ppb	-40°C ~ 85°C
D75J-040.0M	40 MHz	3.3V	±1ppm	-0°C ~ 70°C
T100V-019.2M	19.2 MHz	3.3V	±100ppb	-0°C ~ 70°C
P122-125.0M	125 MHz	2.5V	±50ppm	-0°C ~ 70°C
T622-020.0M	20 MHz	3.3V	±1ppm	-40°C ~ 85°C
CWX813-080.0M	80 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-012.0M	12 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-016.384M	16.384 MHz	3.3V	±25ppm	-20°C ~ 70°C
P123-125.0M	125 MHz	3.3V	±50ppm	-0°C ~ 70°C
TB622-098.304M	98.304 MHz	3.3V	±1ppm	-40°C ~ 85°C
CWX823-001.8432M	1.8432 MHz	3.3V	±50ppm	-20°C ~ 70°C
PM113-200.0M	200 MHz	3.3V	±25ppm	-0°C ~ 70°C
TL602-020.0M	20 MHz	3.3V	±140ppb	-40°C ~ 85°C
CWX823-027.0M	27 MHz	3.3V	±50ppm	-20°C ~ 70°C
P212-125.0M	125 MHz	2.5V	±25ppm	-40°C ~ 85°C
T602-019.2M	19.2 MHz	3.3V	±280ppb	-40°C ~ 85°C
T622-049.152M	49.152 MHz	3.3V	±1ppm	-40°C ~ 85°C
CWX823-025.0M	25 MHz	3.3V	±50ppm	-20°C ~ 70°C
PM113-250.0M	250 MHz	3.3V	±25ppm	-0°C ~ 70°C
T602-025.0M	25 MHz	3.3V	±280ppb	-40°C ~ 85°C
T604-040.0M	40 MHz	3.3V	±280ppb	-40°C ~ 85°C
D75A-012.8M	12.8 MHz	3.3V	±280ppb	-0°C ~ 70°C
XB223-064.0M	64 MHz	3.3V	±50ppm	-40°C ~ 85°C
XB223-060.0M	60 MHz	3.3V	±50ppm	-40°C ~ 85°C
T100V-020.0M	20 MHz	3.3V	±100ppb	-0°C ~ 70°C
TB512-050.0M	50 MHz	3.3V	±500ppb	-0°C ~ 70°C
T622-024.576M	24.576 MHz	3.3V	±1ppm	-40°C ~ 85°C
TB524-100.0M	100 MHz	3.3V	±1ppm	-0°C ~ 70°C
P142-155.52M	155.52 MHz	2.5V	±20ppm	-0°C ~ 70°C
CWX823-033.0M	33 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-020.0M	20 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX823-025.0M	25 MHz	3.3V	±50ppm	-20°C ~ 70°C
PM113-250.0M	250 MHz	3.3V	±25ppm	-0°C ~ 70°C
T604-030.72M	30.72 MHz	3.3V	±280ppb	-40°C ~ 85°C
P222-125.0M	125 MHz	2.5V	±50ppm	-40°C ~ 85°C
P223-100.0M	100 MHz	3.3V	±50ppm	-40°C ~ 85°C
P142-125.0M	125 MHz	2.5V	±20ppm	-0°C ~ 70°C
TB522-100.0M	100 MHz	3.3V	±1ppm	-0°C ~ 70°C
CWX823-125.0M	125 MHz	3.3V	±50ppm	-20°C ~ 70°C
P142-155.52M	155.52 MHz	2.5V	±20ppm	-0°C ~ 70°C
D75J-038.88M	38.88 MHz	3.3V	±1ppm	-0°C ~ 70°C
P143-155.52M	155.52 MHz	3.3V	±20ppm	-0°C ~ 70°C
P143-125.0M	125 MHz	3.3V	±20ppm	-0°C ~ 70°C
T100F-019.2M	19.2 MHz	3.3V	±100ppb	-0°C ~ 70°C
T200F-020.0M	20 MHz	3.3V	±200ppb	-40°C ~ 85°C
CWX813-040.0M	40 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-020.48M	20.48 MHz	3.3V	±25ppm	-20°C ~ 70°C
T602-020.0M	20 MHz	3.3V	±280ppb	-40°C ~ 85°C
TB514-050.0M	50 MHz	3.3V	±500ppb	-0°C ~ 70°C
P122-156.25M	156.25 MHz	2.5V	±50ppm	-0°C ~ 70°C
D75F-025.0M	25 MHz	3.3V	±500ppb	-0°C ~ 70°C
PB223-156.25M	156.25 MHz	3.3V	±50ppm	-40°C ~ 85°C
CWX823-032.768M	32.768 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX823-156.25M	156.25 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX823-010.0M	10 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-025.0M	25 MHz	3.3V	±25ppm	-20°C ~ 70°C
T100F-010.0M	10 MHz	3.3V	±100ppb	-0°C ~ 70°C
CWX813-024.0M	24 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX823-018.432M	18.432 MHz	3.3V	±50ppm	-20°C ~ 70°C
X213-200.0M	200 MHz	3.3V	±25ppm	-40°C ~ 85°C
P143-100.0M	100 MHz	3.3V	±20ppm	-0°C ~ 70°C
P212-156.25M	156.25 MHz	2.5V	±25ppm	-40°C ~ 85°C
T604-010.0M	10 MHz	3.3V	±280ppb	-40°C ~ 85°C
T200F-024.576M	24.576 MHz	3.3V	±200ppb	-40°C ~ 85°C
CWX823-008.0M	8 MHz	3.3V	±50ppm	-20°C ~ 70°C
DV75C-012.8M	12.8 MHz	3.3V	±280ppb	-40°C ~ 85°C
TB622-080.0M	80 MHz	3.3V	±1ppm	-40°C ~ 85°C
CWX823-001.544M	1.544 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-029.4912M	29.4912 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-016.0M	16 MHz	3.3V	±25ppm	-20°C ~ 70°C
V803-100.0M	100 MHz	3.3V	±15ppm	-0°C ~ 70°C
P142-100.00M	100 MHz	2.5V	±20ppm	-0°C ~ 70°C
P142-156.25M	156.25 MHz	2.5V	±20ppm	-0°C ~ 70°C
T100F-020.0M	20 MHz	3.3V	±100ppb	-0°C ~ 70°C
T200F-040.0M	40 MHz	3.3V	±200ppb	-40°C ~ 85°C
CWX823-050.0M	50 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-066.6666M	66.6666 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-064.0M	64 MHz	3.3V	±25ppm	-20°C ~ 70°C
DV75D-020.0M	20 MHz	3.3V	±1ppm	-40°C ~ 85°C
D75F-027.0M	27 MHz	3.3V	±500ppb	-0°C ~ 70°C
CWX813-050.0M	50 MHz	3.3V	±25ppm	-20°C ~ 70°C
T602-038.88M	38.88 MHz	3.3V	±280ppb	-40°C ~ 85°C
T602-030.72M	30.72 MHz	3.3V	±280ppb	-40°C ~ 85°C
CWX823-033.333M	33.333 MHz	3.3V	±50ppm	-20°C ~ 70°C
TB602-038.88M	38.88 MHz	3.3V	±280ppb	-40°C ~ 85°C
TB612-060.0M	60 MHz	3.3V	±500ppb	-40°C ~ 85°C
CWX823-030.0M	30 MHz	3.3V	±50ppm	-20°C ~ 70°C
P213-100.0M	100 MHz	3.3V	±25ppm	-40°C ~ 85°C
TB622-098.304M	98.304 MHz	3.3V	±1ppm	-40°C ~ 85°C
CWX823-001.8432M	1.8432 MHz	3.3V	±50ppm	-20°C ~ 70°C
PM113-200.0M	200 MHz	3.3V	±25ppm	-0°C ~ 70°C
P143-156.25M	156.25 MHz	3.3V	±20ppm	-0°C ~ 70°C
P212-100.0M	100 MHz	2.5V	±25ppm	-40°C ~ 85°C
T604-038.88M	38.88 MHz	3.3V	±280ppb	-40°C ~ 85°C
P212-125.0M	125 MHz	2.5V	±25ppm	-40°C ~ 85°C
LM113-288.0M	288 MHz	3.3V	±25ppm	-0°C ~ 70°C
DV75C-040.0M	40 MHz	3.3V	±280ppb	-40°C ~ 85°C
P122-125.0M	125 MHz	2.5V	±50ppm	-0°C ~ 70°C
D75J-050.0M	50 MHz	3.3V	±1ppm	-0°C ~ 70°C
TB602-050.0M	50 MHz	3.3V	±280ppb	-40°C ~ 85°C
TB622-100.0M	100 MHz	3.3V	±1ppm	-40°C ~ 85°C
CWX823-007.3728M	7.3728 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX823-004.0M	4 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-016.384M	16.384 MHz	3.3V	±25ppm	-20°C ~ 70°C
D75AS-020.0M	20 MHz	3.3V	±250ppb	-0°C ~ 70°C
TB602-049.152M	49.152 MHz	3.3V	±280ppb	-40°C ~ 85°C
T200F-050.0M	50 MHz	3.3V	±200ppb	-40°C ~ 85°C
T200F-010.0M	10 MHz	3.3V	±200ppb	-40°C ~ 85°C
T100V-010.0M	10 MHz	3.3V	±100ppb	-0°C ~ 70°C
CWX823-100.0M	100 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-044.736M	44.736 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-049.152M	49.152 MHz	3.3V	±25ppm	-20°C ~ 70°C
V803-125.0M	125 MHz	3.3V	±15ppm	-0°C ~ 70°C
P213-125.0M	125 MHz	3.3V	±25ppm	-40°C ~ 85°C
CWX813-027.0M	27 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-060.0M	60 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX823-060.0M	60 MHz	3.3V	±50ppm	-20°C ~ 70°C
T602-010.0M	10 MHz	3.3V	±280ppb	-40°C ~ 85°C
CWX823-040.0M	40 MHz	3.3V	±50ppm	-20°C ~ 70°C
CWX813-001.8432M	1.8432 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX813-012.288M	12.288 MHz	3.3V	±25ppm	-20°C ~ 70°C
T604-025.0M	25 MHz	3.3V	±280ppb	-40°C ~ 85°C
CWX823-020.0M	20 MHz	3.3V	±50ppm	-20°C ~ 70°C
DV75D-012.8M	12.8 MHz	3.3V	±1ppm	-40°C ~ 85°C
DV75C-020.0M	20 MHz	3.3V	±280ppb	-40°C ~ 85°C
D75A-010.0M	10 MHz	3.3V	±280ppb	-0°C ~ 70°C
TB522-080.0M	80 MHz	3.3V	±1ppm	-0°C ~ 70°C
D75A-020.0M	20 MHz	3.3V	±280ppb	-0°C ~ 70°C
TB612-100.0M	100 MHz	3.3V	±500ppb	-40°C ~ 85°C
CWX813-030.0M	30 MHz	3.3V	±25ppm	-20°C ~ 70°C
CWX823-064.0M	64 MHz	3.3V	±50ppm	-20°C ~ 70°C
