10MHz晶振,5070晶振,5V,25PPM,CE3291-10.000,Crystek晶振

产品分类：晶振规格书

订购热线：0755-33533774

跟此产品相关的产品

产品详情

型号	频率范围	电压	频率稳定性	工作温度
C3291-16.384	16.384 MHz	5V	±25ppm	-0°C ~ 70°C
CE3290-60.000	60 MHz	5V	±100ppm	-40°C ~ 85°C
CE3291-10.000	10 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-16.384	16.384 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-24.704	24.704 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-3.686400	3.6864 MHz	5V	±25ppm	-40°C ~ 85°C
CE3292-80.000	80 MHz	5V	±50ppm	-40°C ~ 85°C
CE3291-75.000	75 MHz	5V	±25ppm	-40°C ~ 85°C
C3290-100.000	100 MHz	5V	±100ppm	-0°C ~ 70°C
C3390-1.843200	1.8432 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-33.333	33.333 MHz	3.3V	±100ppm	-0°C ~ 70°C
CE3392-1.544	1.544 MHz	3.3V	±50ppm	-40°C ~ 85°C
CE3392-15.360	15.36 MHz	3.3V	±50ppm	-40°C ~ 85°C
CE3392-19.440	19.44 MHz	3.3V	±50ppm	-40°C ~ 85°C
C3391-18.432	18.432 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3391-35.328	35.328 MHz	3.3V	±25ppm	-0°C ~ 70°C
CE3392-49.152	49.152 MHz	3.3V	±50ppm	-40°C ~ 85°C
CE3391-12.352	12.352 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-66.666600	66.6666 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3390-125.000	125 MHz	3.3V	±100ppm	-40°C ~ 85°C
C3292-2.048	2.048 MHz	5V	±50ppm	-0°C ~ 70°C
C3292-8.000	8 MHz	5V	±50ppm	-0°C ~ 70°C
C3290-75.000	75 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-60.000	60 MHz	5V	±50ppm	-0°C ~ 70°C
CE3290-25.000	25 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-16.384	16.384 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-32.768	32.768 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-45.000	45 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-51.840	51.84 MHz	5V	±25ppm	-0°C ~ 70°C
CE3291-25.000	25 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-106.250	106.25 MHz	5V	±25ppm	-40°C ~ 85°C
CE3390-24.704	24.704 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3392-10.000	10 MHz	3.3V	±50ppm	-40°C ~ 85°C
C3391-33.333	33.333 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3391-49.152	49.152 MHz	3.3V	±25ppm	-0°C ~ 70°C
CE3391-24.000	24 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-30.000	30 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3392-64.000	64 MHz	3.3V	±50ppm	-40°C ~ 85°C
CE3391-80.000	80 MHz	3.3V	±25ppm	-40°C ~ 85°C
C3390-133.000	133 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-20.000	20 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-64.000	64 MHz	3.3V	±50ppm	-0°C ~ 70°C
CE3390-8.000	8 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3392-1.843200	1.8432 MHz	3.3V	±50ppm	-40°C ~ 85°C
C3391-24.704	24.704 MHz	3.3V	±25ppm	-0°C ~ 70°C
CE3391-12.000	12 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-32.000	32 MHz	3.3V	±25ppm	-40°C ~ 85°C
C3391-106.250	106.25 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3390-12.000	12 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-20.000	20 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-12.288	12.288 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-2.048	2.048 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-3.686400	3.6864 MHz	3.3V	±50ppm	-0°C ~ 70°C
CE3390-30.000	30 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-32.000	32 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3392-12.000	12 MHz	3.3V	±50ppm	-40°C ~ 85°C
C3391-24.000	24 MHz	3.3V	±25ppm	-0°C ~ 70°C
CE3391-18.432	18.432 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-20.480	20.48 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-4.000	4 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-100.000	100 MHz	3.3V	±25ppm	-40°C ~ 85°C
C3391-133.000	133 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3290-8.000	8 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-12.000	12 MHz	5V	±50ppm	-0°C ~ 70°C
C3292-12.352	12.352 MHz	5V	±50ppm	-0°C ~ 70°C
C3291-12.288	12.288 MHz	5V	±25ppm	-0°C ~ 70°C
CE3292-106.250	106.25 MHz	5V	±50ppm	-40°C ~ 85°C
C3290-18.432	18.432 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-14.318180	14.31818 MHz	5V	±50ppm	-0°C ~ 70°C
CE3290-16.000	16 MHz	5V	±100ppm	-40°C ~ 85°C
CE3290-7.372800	7.3728 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-1.843200	1.8432 MHz	5V	±50ppm	-40°C ~ 85°C
CE3292-24.704	24.704 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-20.480	20.48 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-3.686400	3.6864 MHz	5V	±25ppm	-0°C ~ 70°C
CE3292-50.000	50 MHz	5V	±50ppm	-40°C ~ 85°C
CE3291-35.000	35 MHz	5V	±25ppm	-40°C ~ 85°C
C3291-64.000	64 MHz	5V	±25ppm	-0°C ~ 70°C
CE3290-100.000	100 MHz	5V	±100ppm	-40°C ~ 85°C
C3290-12.000	12 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-20.000	20 MHz	5V	±50ppm	-0°C ~ 70°C
C3292-80.000	80 MHz	5V	±50ppm	-0°C ~ 70°C
CE3290-1.544	1.544 MHz	5V	±100ppm	-40°C ~ 85°C
CE3290-16.384	16.384 MHz	5V	±100ppm	-40°C ~ 85°C
CE3290-2.048	2.048 MHz	5V	±100ppm	-40°C ~ 85°C
CE3290-24.000	24 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-3.686400	3.6864 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-12.000	12 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-15.360	15.36 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-19.440	19.44 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-25.000	25 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-8.000	8 MHz	5V	±25ppm	-0°C ~ 70°C
CE3291-12.000	12 MHz	5V	±25ppm	-40°C ~ 85°C
C3291-106.250	106.25 MHz	5V	±25ppm	-0°C ~ 70°C
C3390-16.000	16 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-16.384	16.384 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-8.064	8.064 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-1.544	1.544 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-12.352	12.352 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-34.368	34.368 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3290-14.318180	14.31818 MHz	5V	±100ppm	-0°C ~ 70°C
C3290-16.384	16.384 MHz	5V	±100ppm	-0°C ~ 70°C
C3290-64.000	64 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-20.480	20.48 MHz	5V	±50ppm	-0°C ~ 70°C
C3292-4.000	4 MHz	5V	±50ppm	-0°C ~ 70°C
CE3290-32.768	32.768 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-20.000	20 MHz	5V	±50ppm	-40°C ~ 85°C
CE3292-20.480	20.48 MHz	5V	±50ppm	-40°C ~ 85°C
CE3292-24.000	24 MHz	5V	±50ppm	-40°C ~ 85°C
CE3292-40.000	40 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-20.000	20 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-4.000	4 MHz	5V	±25ppm	-0°C ~ 70°C
CE3292-49.152	49.152 MHz	5V	±50ppm	-40°C ~ 85°C
CE3291-14.318180	14.31818 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-15.360	15.36 MHz	5V	±25ppm	-40°C ~ 85°C
C3390-12.288	12.288 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-15.360	15.36 MHz	3.3V	±100ppm	-0°C ~ 70°C
CE3390-12.352	12.352 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-16.000	16 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-16.384	16.384 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-2.048	2.048 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-66.666600	66.6666 MHz	3.3V	±100ppm	-40°C ~ 85°C
C3391-66.666600	66.6666 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3391-100.000	100 MHz	3.3V	±25ppm	-0°C ~ 70°C
CE3391-106.250	106.25 MHz	3.3V	±25ppm	-40°C ~ 85°C
C3290-12.352	12.352 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-18.432	18.432 MHz	5V	±50ppm	-0°C ~ 70°C
CE3292-1.544	1.544 MHz	5V	±50ppm	-40°C ~ 85°C
CE3292-8.000	8 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-2.048	2.048 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-40.000	40 MHz	5V	±25ppm	-0°C ~ 70°C
CE3291-20.480	20.48 MHz	5V	±25ppm	-40°C ~ 85°C
C3390-20.480	20.48 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-30.000	30 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-6.176	6.176 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-30.000	30 MHz	3.3V	±50ppm	-0°C ~ 70°C
CE3390-1.544	1.544 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-18.432	18.432 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-24.000	24 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3392-12.288	12.288 MHz	3.3V	±50ppm	-40°C ~ 85°C
C3391-20.000	20 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3390-34.368	34.368 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3390-45.000	45 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-19.440	19.44 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-4.000	4 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-66.666600	66.6666 MHz	3.3V	±50ppm	-0°C ~ 70°C
CE3392-14.318180	14.31818 MHz	3.3V	±50ppm	-40°C ~ 85°C
CE3392-32.000	32 MHz	3.3V	±50ppm	-40°C ~ 85°C
C3391-16.384	16.384 MHz	3.3V	±25ppm	-0°C ~ 70°C
C3391-8.000	8 MHz	3.3V	±25ppm	-0°C ~ 70°C
CE3391-35.000	35 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3391-60.000	60 MHz	3.3V	±25ppm	-40°C ~ 85°C
CE3390-155.520	155.52 MHz	3.3V	±100ppm	-40°C ~ 85°C
C3290-16.000	16 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-1.843200	1.8432 MHz	5V	±50ppm	-0°C ~ 70°C
C3292-33.333	33.333 MHz	5V	±50ppm	-0°C ~ 70°C
CE3290-1.843200	1.8432 MHz	5V	±100ppm	-40°C ~ 85°C
CE3290-40.000	40 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-25.000	25 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-1.843200	1.8432 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-33.333	33.333 MHz	5V	±25ppm	-0°C ~ 70°C
CE3290-50.000	50 MHz	5V	±100ppm	-40°C ~ 85°C
CE3290-64.000	64 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-66.666600	66.6666 MHz	5V	±50ppm	-40°C ~ 85°C
CE3291-51.840	51.84 MHz	5V	±25ppm	-40°C ~ 85°C
C3292-100.000	100 MHz	5V	±50ppm	-0°C ~ 70°C
C3290-20.000	20 MHz	5V	±100ppm	-0°C ~ 70°C
C3290-6.176	6.176 MHz	5V	±100ppm	-0°C ~ 70°C
C3292-3.686400	3.6864 MHz	5V	±50ppm	-0°C ~ 70°C
C3290-80.000	80 MHz	5V	±100ppm	-0°C ~ 70°C
CE3290-6.176	6.176 MHz	5V	±100ppm	-40°C ~ 85°C
C3291-10.000	10 MHz	5V	±25ppm	-0°C ~ 70°C
C3291-24.704	24.704 MHz	5V	±25ppm	-0°C ~ 70°C
CE3291-32.000	32 MHz	5V	±25ppm	-40°C ~ 85°C
C3390-32.000	32 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-16.384	16.384 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-25.000	25 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3390-64.000	64 MHz	3.3V	±100ppm	-0°C ~ 70°C
CE3390-10.000	10 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-33.333	33.333 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3390-40.000	40 MHz	3.3V	±100ppm	-40°C ~ 85°C
CE3392-12.352	12.352 MHz	3.3V	±50ppm	-40°C ~ 85°C
CE3390-106.2500	106.25 MHz	3.3V	±100ppm	-40°C ~ 85°C
C3392-125.000	125 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-156.250	156.25 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3292-64.000	64 MHz	5V	±50ppm	-0°C ~ 70°C
CE3290-24.704	24.704 MHz	5V	±100ppm	-40°C ~ 85°C
CE3292-12.000	12 MHz	5V	±50ppm	-40°C ~ 85°C
C3291-49.152	49.152 MHz	5V	±25ppm	-0°C ~ 70°C
CE3290-44.736	44.736 MHz	5V	±100ppm	-40°C ~ 85°C
CE3291-12.288	12.288 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-8.000	8 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-49.152	49.152 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-50.000	50 MHz	5V	±25ppm	-40°C ~ 85°C
CE3291-64.000	64 MHz	5V	±25ppm	-40°C ~ 85°C
C3390-25.000	25 MHz	3.3V	±100ppm	-0°C ~ 70°C
C3392-33.333	33.333 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-40.000	40 MHz	3.3V	±50ppm	-0°C ~ 70°C
C3392-51.840	51.84 MHz	3.3V	±50ppm	-0°C ~ 70°C
CE3392-2.048	2.048 MHz	3.3V	±50ppm	-40°C ~ 85°C
