随着汽车和道路的建设，城际间的交通往来更加频繁，GPS导航可以实现定位、导航和娱乐功能，在现代行车更重要的人的车载GPS导航，已成为不可或缺的汽车产品。车载导航的最初定义是使用电子地图的车载gps（全球定位系统），它能方便、准确地告诉驾驶员到达最短或最快路径的目的地。随着汽车工业的发展，竞争越来越激烈。为了满足人们的舒适和方便，人们对车载导航显示模块提出了更高的要求。同时，更多的集成，更多的功能的设计，也对车载计算机，导航和其他产品的发展趋势。
那么用在北斗+GPS/GPRS车辆定位晶振品牌型号有哪些呢？
KDS晶振品牌系列：
| 无源crystal系列： | |||||
型号 | 频率 | 负载电容 | 精度 | 体积 | 工作温度 |
DT-26 | 32.768KHz | 12.5PF 6PF | ±5PPM ±10PPM ±20PPM | 2x6 | -10°C+60°C -40°C+85°C |
DT-38 | 32.768KHz | 12.5PF | ±5PPM ±10PPM ±20PPM | 2x6 | -10°C+60°C -40°C+85°C |
| DMX-26S | 32.768KHz | 12.5PF 6PF | ±20PPM | 8.0x3.8mm | -40°C+85°C |
| DST1610A | 32.768KHz | 12.5PF 6PF | ±20PPM | 1.6x1.0mm | -40°C+85°C |
| DST210A | 32.768KHz | 12.5PF 6PF | ±20PPM | 2.0x1.2mm | -40°C+85°C |
| DST310S | 32.768KHz | 6PF 7PF 9PF 12.5PF | ±20PPM | 3.2x1.5mm | -40°C+85°C |
| DSX321G | 26MHz | 19PF | ±7PPM | 3.2x2.5mm | -40°C+85°C |
| DSX221G | 26MHz | 19PF | ±7PPM | 2.5x2.0mm | -40°C+85°C |
| TCXO温补晶振系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| DSB321SDA/M/N | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 3.2x2.5mm | -40°C+85°C |
| DSB221SDA/M/N | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.5x2.0mm | -40°C+85°C |
| DSB211SDA/M/N | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.0x1.6mm | -40°C+85°C |
| DSB535SD | 10MHz/16.32MHz | 10PF | ±0.5PPM | 5.0x3.2mm | -40°C+85°C |
| DSB321SDA | 10MHz/16.32MHz | 10PF | ±0.5PPM | 3.2x2.5mm | -40°C+85°C |
爱普生晶振品牌系列：
| 无源crystal系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| FC1610AN | 32.768KHz | 12.5PF 9PF | ±20PPM | 1.6x1.0mm | -40°C+85°C |
| FC-12M | 32.768KHz | 12.5PF 9PF | ±20PPM | 2.0x1.2mm | -40°C+85°C |
| FC-135 | 32.768KHz | 6PF 7PF 9PF 12.5PF | ±20PPM | 3.2x1.5mm | -40°C+85°C |
| MC-146 | 32.768KHz | 7PF 9PF12.5PF | ±20PPM | 7.0x1.5mm | -40°C+85°C |
| MC-306 | 32.768KHz | 6PF 12.5PF | ±20PPM | 8.0x3.8mm | -40°C+85°C |
C-002RX | 32.768KHz | 6PF 12.5PF | ±5PPM ±10PPM ±20PPM | 2x6 | -10°C+60°C |
| FA-20H | 26MHz | 19PF | ±7PPM | 2.5x2.0mm | -40°C+85°C |
| TSX-3225 | 26MHz | 19PF | ±7PPM | 3.2x2.5mm | -40°C+85°C |
| TCXO温补晶振系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
TG-5006CJ | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.0x1.6mm | -40°C+85°C |
| TG-5006CG | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.5x2.0mm | -40°C+85°C |
| TG-5006CE | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 3.2x2.5mm | -40°C+85°C |
| TG5032CDN | 10MHz/16.32MHz | 10PF | ±0.5PPM | 5.0x3.2mm | -40°C+85°C |
NDK晶振品牌系列：
| 无源crystal系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| NX1610SA | 32.768KHz | 6PF 9PF 12.5PF | ±20PPM | 1.6x1.0mm | -40°C+85°C |
| NX2012SA | 32.768KHz | 6PF 9PF 12.5PF | ±20PPM | 2.0x1.2mm | -40°C+85°C |
| NX3215SA | 32.768KHz | 6PF 9PF 12.5PF | ±20PPM | 3.2x1.5mm | -40°C+85°C |
| NX2520SA | 26MHz | 19PF | ±7PPM | 2.5x2.0mm | -40°C+85°C |
| NX3225SA | 26MHz | 19PF | ±7PPM | 3.2x2.5mm | -40°C+85°C |
TCXO温补晶振系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| NT2016SA | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10Pf | ±0.5PPM | 2.0x1.6mm | -40°C+85°C |
| NT2520SB | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.5x2.0mm | -40°C+85°C |
| NT3225SA | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 3.2x2.5mm | -40°C+85°C |
京瓷晶振品牌系列：
| 无源crystal系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| ST2010SB | 32.768KHz | 6PF 7PF 9PF 12.5PF | ±20PPM | 2.0x1.2mm | -40°C+85°C |
| ST3215SB | 32.768KHz | 6PF 7PF 9PF 12.5PF | ±20PPM | 3.2x1.5mm | -40°C+85°C |
CX2520DB | 26MHz | 9PF | ±19PPM | 2.5x2.0mm | -30°C+85°C |
| CX3225SB | 26MHz | 9PF | ±19PPM | 3.2x2.5mm | -30°C+85°C |
| TCXO温补晶振系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| KT2016K | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.0x1.6mm | -30°C+85°C |
| KT2520K | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.5x2.0mm | -30°C+85°C |
| KT3225K | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 3.2x2.5mm | -30°C+85°C |
TXC晶振品牌系列：
| 无源crystal系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| 9HT12 | 32.768KHz | 6PF 9PF 12.5PF | ±20PPM | 1.6x1.2mm | -40°C+85°C |
| 9HT11 | 32.768KHz | 6PF 7PF 9PF 12.5PF | ±20PPM | 2.0x1.2mm | -40°C+85°C |
| 9HT10 | 32.768KHz | 6PF 7PF 9PF 12.5PF | ±20PPM | 3.2x1.5mm | -40°C+85°C |
| 7M | 26MHz | 19PF | ±7PPM | 3.2x2.5mm | -40°C+85°C |
| 8Z | 26MHz | 19PF | ±7PPM | 2.5x2.0mm | -40°C+85°C |
TCXO温补晶振系列： | |||||
| 型号 | 频率 | 负载电容 | 精度 | 封装 | 温度 |
| 7Q | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 3.2x2.5mm | -40°C+85°C |
| 7L | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.5x2.0mm | -40°C+85°C |
| 7Z | 16.367667MHz/16.368MMHz/16.369MHz/26MHz | 10PF | ±0.5PPM | 2.0x1.6mm | -40°C+85°C |
如果您正在寻找原装正品晶振,请选择加科电子。我们保障让您的工作得到前所未有的高效化。深圳市加科电子科技有限公司：主要代理日系一线品牌晶振，爱普生晶振，西铁城晶振，精工晶振，KDS晶体，村田陶瓷谐振器，NDK晶振，KSS晶振，是国内的一家进口晶振代理商，厂家同时生产32.768K圆柱晶振，以及陶瓷晶振，雾化片，滤波器等压电晶体。在实力上，加科电子拥有多个品牌晶振的代理资质，因此加科电子是您的选择。我们保证原装正品，频点齐全，供货交期短，现货库存，可免费试样。如需更详细的了解该产品的技术或者详细规格书，请直接来电咨询我们联系业务员。电话：15602443498 企业官网：www.xtal.cc QQ:3080074590 邮箱:jiakedz@163.com
