8Z12070004晶振开启高清网络摄像头物联时代

文章出处：http://www.xtal.cc/责任编辑：加科电子人气：-发表时间：2022-11-11 09:30【大 中 小】

为了确保高清网络摄像头在室外温度变化较大的恶劣环境中仍能保持监控视频的流畅和高清,通常需要一个尺寸小（2520贴片晶振或2016封装,1612封装）,精度高,稳定性高,温度宽的外置12MHz贴片无源晶振,精度通常在±20ppm以内,温度漂移在±50ppm以内。

TXC晶振

为了满足上述贴片crystal晶振高精度选择的要求建议选择TXC晶振12MHz无源晶振8Z12070004,典型负载电容为12pF,精度10ppm,室温25℃时频率调节差为±10ppm,全温时频率稳定度为±30ppm,可满足高精度,低温漂移的设计要求,工作温度范围-20℃~85℃。

8Z（2520封装）系列


料号频率精度负载电容工业温度
8Z1201000212 MHz±30ppm16pF-20°C ~ 70°C
8Z1207000412 MHz±10ppm12pF-20°C ~ 85°C
8Z1207700112 MHz±30ppm12pF-20°C ~ 70°C
8Z1209000112 MHz±30ppm18pF-40°C ~ 85°C
8Z1600000116 MHz±10ppm10pF-20°C ~ 75°C
8Z1600000216 MHz±10ppm9pF-20°C ~ 75°C
8Z1607001716 MHz±10ppm10pF-40°C ~ 85°C
8Z1660000116.66667 MHz±30ppm12pF-40°C ~ 85°C
8Z1922000119.2 MHz±30ppm12pF-20°C ~ 70°C
8Z2000001020 MHz±7ppm16pF-20°C ~ 70°C
8Z2000002920 MHz±7ppm16pF-20°C ~ 100°C
8Z2007000320 MHz±10ppm12pF-20°C ~ 85°C
8Z2007000520 MHz±7ppm16pF-20°C ~ 85°C
8Z2007001020 MHz±7ppm8pF-20°C ~ 70°C
8Z2007001220 MHz±10ppm10pF-20°C ~ 70°C
8Z2400002824 MHz±30ppm16pF-25°C ~ 70°C
8Z2400004624 MHz±30ppm8pF-20°C ~ 70°C
8Z2407000224 MHz±10ppm10pF-20°C ~ 85°C
8Z2407001024 MHz±30ppm18pF-40°C ~ 85°C
8Z2407001624 MHz±10ppm18pF-20°C ~ 70°C
8Z2500001025 MHz±30ppm18pF-20°C ~ 70°C
8Z2500001225 MHz±30ppm12pF-20°C ~ 70°C
8Z2502000225 MHz±30ppm18pF-40°C ~ 85°C
8Z2507000125 MHz±30ppm18pF-30°C ~ 85°C
8Z2507000625 MHz±30ppm18pF-40°C ~ 85°C
8Z2507000725 MHz±30ppm16pF-30°C ~ 85°C
8Z2600001226 MHz±10ppm7pF-20°C ~ 75°C
8Z2600002126 MHz±10ppm8pF-30°C ~ 85°C
8Z2600002226 MHz±10ppm8pF-30°C ~ 85°C
8Z2600002426 MHz±10ppm8pF-30°C ~ 85°C
8Z2600002526 MHz±10ppm9pF-30°C ~ 85°C
8Z2600002626 MHz±10ppm10pF-20°C ~ 75°C
8Z2600002826 MHz±10ppm10pF-20°C ~ 85°C
8Z2600003526 MHz±10ppm9pF-20°C ~ 75°C
8Z2600003926 MHz±10ppm18pF-30°C ~ 85°C
8Z2600004826 MHz±10ppm8pF-30°C ~ 85°C
8Z2600005326 MHz±10ppm8pF-25°C ~ 70°C
8Z2600005426 MHz±10ppm11pF-20°C ~ 75°C
8Z2607000126 MHz±10ppm10pF-20°C ~ 85°C
8Z2700000127 MHz±10ppm10pF-20°C ~ 70°C
8Z2702000227 MHz±30ppm18pF-40°C ~ 85°C
8Z2707000727 MHz±30ppm18pF-40°C ~ 85°C
8Z2707001227 MHz±10ppm10pF-20°C ~ 70°C
8Z2710000127.12 MHz±10ppm10pF-20°C ~ 70°C
8Z3007000330 MHz±10ppm10pF-20°C ~ 75°C
8Z3007700130 MHz±10ppm10pF-20°C ~ 70°C
8Z3127000131.25 MHz±20ppm18pF-20°C ~ 75°C
8Z3740000437.4 MHz-17ppm、+3ppm10pF-10°C ~ 85°C
8Z3747000437.4 MHz±10ppm10pF-30°C ~ 85°C
8Z3840002738.4 MHz±10ppm10pF-30°C ~ 85°C
8Z3842000138.4 MHz±30ppm12pF-20°C ~ 70°C
8Z3842000338.4 MHz±20ppm8pF-40°C ~ 85°C
8Z3847000938.4 MHz±10ppm8pF-30°C ~ 85°C
8Z4000001740 MHz±5ppm12pF-20°C ~ 100°C
8Z4000003040 MHz±7ppm8pF-40°C ~ 90°C
8Z4000004640 MHz±7ppm18pF-20°C ~ 85°C
8Z4002000540 MHz±10ppm7.5pF-30°C ~ 85°C
8Z4007000740 MHz±7ppm12pF-20°C ~ 85°C
8Z4007700840 MHz±10ppm9pF-30°C ~ 85°C
8Z4009000540 MHz±3ppm12pF-5°C ~ 100°C
8Z4009000640 MHz±10ppm12pF-30°C ~ 85°C
8Z4009000940 MHz±9ppm12pF-30°C ~ 85°C
8Z4009001040 MHz±9ppm12pF-40°C ~ 85°C
8Z4910000149.152 MHz±30ppm9pF-30°C ~ 85°C



AZ(2520车规封装)系列

料号频率精度负载电容工业温度
AZ1600000316 MHz±10ppm10pF-40°C ~ 85°C
AZ2007000320 MHz±30ppm12pF-40°C ~ 125°C
AZ4006000140 MHz±10ppm7pF-40°C ~ 105°C




8Y（2016封装）系列


料号频率精度负载电容工业温度
8Y1600000116 MHz±10ppm28pF-20°C ~ 85°C
8Y1602000116 MHz±30ppm8pF-20°C ~ 70°C
8Y1607000116 MHz±30ppm8pF-20°C ~ 70°C
8Y1607000416 MHz±30ppm8pF-20°C ~ 70°C
8Y1607000616 MHz±10ppm12pF-20°C ~ 70°C
8Y1607700116 MHz±10ppm8pF-10°C ~ 70°C
8Y1920000119.2 MHz±30ppm12pF-20°C ~ 70°C
8Y1922000119.2 MHz±30ppm12pF-20°C ~ 70°C
8Y2402000224 MHz±30ppm18pF-40°C ~ 85°C
8Y2407000324 MHz±10ppm10pF-20°C ~ 75°C
8Y2407000724 MHz±10ppm10pF-40°C ~ 85°C
8Y2407600124 MHz±30ppm6pF-40°C ~ 85°C
8Y2507001025 MHz±30ppm6pF-30°C ~ 85°C
8Y2507001125 MHz±10ppm8pF-20°C ~ 75°C
8Y2507001625 MHz±30ppm18pF-40°C ~ 85°C
8Y2600000526 MHz±10ppm12pF-30°C ~ 85°C
8Y2600000926 MHz±10ppm18pF-20°C ~ 70°C
8Y2602000226 MHz±20ppm8pF-20°C ~ 70°C
8Y2607001426 MHz±10ppm10pF-30°C ~ 85°C
8Y2710000127.12 MHz±10ppm10pF-20°C ~ 75°C
8Y2710000227.12 MHz±30ppm12pF-20°C ~ 70°C
8Y2712000327.12 MHz±30ppm18pF-20°C ~ 70°C
8Y3200000432 MHz±10ppm8pF-30°C ~ 75°C
8Y3200500132 MHz±10ppm12pF-20°C ~ 75°C
8Y3747000737.4 MHz±10ppm8pF-30°C ~ 85°C
8Y3847201238.4 MHz±10ppm10pF-20°C ~ 70°C
8Y4007200240 MHz-8pF-20°C ~ 70°C
8Y4807200748 MHz-8pF-20°C ~ 70°C
8Y4807700148 MHz±15ppm10pF-20°C ~ 70°C
8Y4809000248 MHz-6ppm，+8ppm8.8pF-30°C ~ 85°C
8Y5007000150 MHz±10ppm8pF-20°C ~ 70°C
8Y5007200250 MHz±7ppm9pF-40°C ~ 105°C


8Q(1612封装)系列


料号频率精度负载电容工业温度
8Q2400000124 MHz±30ppm10pF-20°C ~ 75°C
8Q2401000624 MHz±30ppm9.5pF-25°C ~ 70°C
8Q2407000124 MHz±10ppm10pF-10°C ~ 60°C
8Q2507000325 MHz±10ppm8pF-40°C ~ 85°C
8Q2607700326 MHz±10ppm8pF-20°C ~ 70°C
8Q3007700130 MHz±10ppm8pF-20°C ~ 70°C
8Q3742000137.4 MHz±10ppm16pF-30°C ~ 85°C
8Q3747000137.4 MHz±10ppm16pF-30°C ~ 85°C
8Q3747000737.4 MHz±10ppm12pF-30°C ~ 85°C
8Q3847000338.4 MHz±10ppm10pF-30°C ~ 85°C
8Q4001000440 MHz±9ppm5.8pF-30°C ~ 85°C
8Q4007000340 MHz±7ppm12pF-30°C ~ 85°C
8Q5007700150 MHz±15ppm8pF-40°C ~ 85°C
8QA8070001180 MHz±10ppm10pF-40°C ~ 85°C

台湾晶技TXC公司8Z12070004晶振采用2520小尺寸封装,可节省PCB板空间,便于产品小型化设计,它具有高稳定的性能,在市场上具有成熟的应用设计,并且产品性能已得到验证,8Z晶体以其额定频率范围:12MHz~66MHz,外部尺寸:2.5×2.0×0.55mm等特点可非常好地应用于无线通信模块等领域。

此文关键字：8Z12070004晶振 TXC晶振 2520贴片晶振 晶振 8Z
