蓝牙技术作为短距离无线通信的行业标准,已经是便携式消费电子产品的标配,蓝牙的主板是集于电容,电阻,晶振和射频收发等器件组成的,蓝牙质量的好与坏是与电子元器件是有关联的如何选择一款合适的性价比晶振了下面就介绍一款NDK晶振公司的26MHz晶振NX3225SA-26MHZ-STD-CQR-1小体积3225贴片晶振,此款负载电容8PF,精度10PPM,工作温度-40+85度,尺寸仅有尺寸为3.2×2.5×0.55mm,26MHz晶振主要应用于各类小型化电子产品所需之频率需求。
NX3225SA-26MHZ-STD-CQR-1晶振的用途如下：
无线射频：NX3225SA-26MHZ-STD-CQR-1晶振产品在无线通信系统中被广泛使用,如蓝牙,WiFi,Zigbee等。
智慧城市：智慧城市中的智能家居,智能交通等系统都采用了NX3225SA-26MHZ-STD-CQR-1进行无线通信。
无线充电：无线充电系统中也使用了NX3225SA-26MHZ-STD-CQR-1晶振作为时钟基准。
新能源：太阳能,风能等新能源系统中,NX3225SA-26MHZ-STD-CQR-1被用于控制逆变器和转换器等设备。
工业仪器：工业仪器中的各种传感器和执行器都采用了NX3225SA-26MHZ-STD-CQR-1晶振进行信号传输和处理。
| 料号 | 频率 | 频率容差 | 负载电容 | 工作温度 |
| NX3225SA-12.000M-STD-CRS-2 | 12MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-16MHZ-EXS00A-CS14520 | 16MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-32MHZ-EXS00A-CS14526 | 32MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-24MHZ-EXS00A-CS14522 | 24MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-40M-EXS00A-CS03880 | 40MHz | ±10ppm | 10pF | -40°C ~ 85°C |
| NX3225SA-12MHZ-EXS00A-CS15202 | 12MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-16MHZ-STD-CQR-1 | 16MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-12MHZ-STD-CSR-6 | 12MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-16.000000MHZ-T1 | 16MHz | ±10ppm | 10pF | -20°C ~ 70°C |
| NX3225SA-26.000000MHZ-G4 | 26MHz | ±10ppm | 10pF | -20°C ~ 70°C |
| NX3225SA-16.000M-STD-CRS-2 | 16MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-25.000M-STD-CRS-2 | 25MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-20MHZ-EXS00A-CS14521 | 20MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-27MHZ-EXS00A-CS14525 | 27MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-32M-EXS00A-02994 | 32MHz | ±10ppm | 16pF | -30°C ~ 85°C |
| NX3225SA-32MHZ-EXS00A-CS02368 | 32MHz | ±10ppm | 9pF | -40°C ~ 85°C |
| NX3225SA-40MHZ-EXS00A-CS14527 | 40MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-20.000000MHZ-B2 | 20MHz | ±10ppm | 7.2pF | -30°C ~ 85°C |
| NX3225SA-20.000M-STD-CRS-2 | 20MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-25MHz-STD-CQR-1 | 25MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-24.576MHz-EXS00A-CS14523 | 24.576MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-27.12MHz-EXS00A-CS14516 | 27.12MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-13.56MHz-EXS00A-CS15188 | 13.56MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-16.000000MHZ-B3 | 16MHz | ±10ppm | 7.2pF | -30°C ~ 85°C |
| NX3225SA-26.000M-STD-CSQ-1 | 26MHz | ±10ppm | 10pF | -20°C ~ 75°C |
| NX3225SA-26MHZ-EXS00A-CS14518 | 26MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-14.31818MHZ-EXS00A-CS14517 | 25MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-14.31818M-STD-CSR-1 | 14.31818MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-16M-EXS00A-CS05997 | 16MHz | - | 8pF | - |
| NX3225SA-32MHZ-EXS00A-CS08207 | 32MHz | - | 10pF | - |
| NX3225SA-12.000M-STD-CSR-1 | 12MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-26.000000MHZ-G3 | 26MHz | ±10ppm | 7.36pF | -20°C ~ 85°C |
| NX3225SA-26.000000MHZ-B1 | 26MHz | ±10ppm | 10pF | -20°C ~ 70°C |
| NX3225SA-24MHZ-EXS00A-CS07532 | 24MHz | - | 9pF | -40°C ~ 150°C |
| NX3225SA-25MHZ-EXS00A-CS11338 | 25MHz | ±30ppm | 18pF | -20°C ~ 70°C |
| NX3225SA-24.305MHZ-EXS00A-CS08559 | 24.305MHz | - | 7pF | - |
| NX3225SA-26MHZ-EXS00A-CS14524 | 26MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-114.285MHZ-EXS00A-CS06528 | 114.285MHz | ±20ppm | 18pF | -40°C ~ 85°C |
| NX3225SA-39.000000MHZ-B4 | 39MHz | ±10ppm | 12pF | -20°C ~ 70°C |
| NX3225SA-24.000M-STD-CSR-3 | 24MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-22.000M-STD-CSR-1 | 22MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-25.000MHZ-STD-CSR-1 | 25MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-12.288MHZ-EXS00A-CS15187 | 12.288MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-13M-STD-CSR-6 | 13MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-12.288M-STD-CRS-2 | 12.288MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-20.000M-STD-CSR-3 | 20MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225A-30MHZ-EXS00A-CS15191 | 30MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-44.000M-STD-CSR-1 | 44MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-27M-STD-CRS-2 | 27MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-16MHZ-STD-CSR-3 | 16MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-16.000MHZ-EXS00A-03311 | 16MHz | ±10ppm | 7.2pF | -10°C ~ 70°C |
| NX3225SA-40.000M-STD-CRS-2 | 40MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-26MHZ-EXS00A-CS08035 | 26MHz | - | 12pF | -40°C ~ 150°C |
| NX3225SA-26.000000MHZ-G2 | 26MHz | ±10ppm | 10pF | -20°C ~ 75°C |
| NX3225SA-40.000MHZ-STD-CRS-2 | 40MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-16MHZ-EXS00A-CS09652 | 16MHz | ±15ppm | 8pF | |
| NX3225SA-20.000MHZ-STD-CRS-2 | 20MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-12.000MHZ-STD-CRS-2 | 12MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-16.000MHZ-STD-CRS-2 | 16MHz | ±15ppm | 8pF | - |
| NX3225SA-13.560MHZ-STD-CSR-3 | 13.56MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-12.000MHZ-STD-CQR-1 | 12MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-24.000MHZ-STD-CQR-1 | 24MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-26.000MHZ-EXS00A-CS00468 | 26MHz | ±10ppm | 10pF | - |
| NX3225SA-24.000MHZ-STD-CSR-6 | 24MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-26.000MHZ-STD-CRS-2 | 26MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-20.000M-EXS00A-CS08671 | 20MHz | ±15ppm | 8pF | - |
| NX3225SA-27.000M-STD-CRS-2 | 27MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-24.000MHZ-EXS00A-CS08708 | 24MHz | ±10ppm | 10pF | - |
| NX3225SA-24.000MHZ-EXS00A-CS06554 | 24MHz | ±10ppm | 12pF | - |
| NX3225SA-16.000MHZ-EXS00A-CS12190 | 16MHz | ±15ppm | 8pF | - |
| NX3225SA-26.000MHZ-EXS00A-CS12191 | 26MHz | ±15ppm | 8pF | - |
| NX3225SA-32.000MHZ-STD-CSR-1 | 32MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-26MHZ-STD-CQR-1 | 26MHz | ±10ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-16MHz-STD-CSR-6 | 16MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-25MHz-STD-CSR-6 | 25MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-27MHZ-STD-CSR-6 | 27MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-26MHz-STD-CSR-6 | 26MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-30MHz-STD-CSR-6 | 30MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-26MHZ-W-168-491-1 | 26MHz | ±10ppm | 7.36pF | -20°C ~ 85°C |
| NX3225SA-25.000MHz-STD-CRS-2 | 25MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-24MHZ-EXS00A-CS08583 | 24MHz | ±10ppm | 9pF | -40°C ~ 85°C |
| NX3225SA-16MHZ-EXS00A-CS10477 | 16MHz | ±50ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-12MHZ-EXS00A-CS13443 | 12MHz | - | - | -40°C ~ 125°C |
| NX3225SA-12MHz-EXS00A-CS06252 | 12MHz | ±10ppm | 10pF | -20°C ~ 70°C |
| NX3225SA-27.6MHZ-EXS00A-CS10286 | 27.6MHz | ±50ppm | 10pF | -40°C ~ 125°C |
| NX3225SA-21.948717MHZ-EXS00A-CS10343 | 21.948717MHz | ±50ppm | 12pF | -40°C ~ 125°C |
| NX3225SA-24M-STD-CSR-1 | 24MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-24M-STD-CRS-2 | 24MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-26MHZ-191-866 | 26MHz | - | - | - |
| NX3225SA-12MHZ-STD-CRS-2 | 12MHz | ±15ppm | 8pF | -40°C ~ 125°C |
| NX3225SA-26MHZ-W-211-133 | 26MHz | - | - | - |
| NX3225SA-12MHZ-STD-CSR-3 | 12MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-27.12M-STD-CSR-3 | 27.12MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-13.56M-STD-CSR-3 | 13.56MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-32.000M-STD-CSR-1 | 32MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-16.000M-STD-CSR-1 | 16MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-40.000M-STD-CSR-1 | 40MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-26.000M-STD-CSR-3 | 26MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-26.000M-STD-CSR-1 | 26MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-24.576M-STD-CSR-1 | 24.576MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-30.000M-STD-CSR-3 | 30MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-20.000M-STD-CSR-1 | 20MHz | ±15ppm | 8pF | -10°C ~ 70°C |
| NX3225SA-25.000M-STD-CSR-6 | 25MHz | ±15ppm | 8pF | -40°C ~ 85°C |
| NX3225SA-25.000M-STD-CSR-3 | 25MHz | ±15ppm | 8pF | -10°C ~ 75°C |
| NX3225SA-12MHZ-EXS00A-CS06619 | 12MHz | - | - | - |
| NX3225SA-12MHZ-EXS00A-CS01257 | 12MHz | - | - | - |
| NX3225SA-26MHZ-EXS00A-CS00030-1 | 26MHz | ±8ppm | 10pF | - |
| NX3225SA-28.63636M-EXS00A-CS09644 | 28.63636MHz | - | - | - |
NX3225SA-26MHZ-STD-CQR-1晶振的特点如下：
高精度：NX3225SA-26MHZ-STD-CQR-1晶振的频率偏差（@25℃）仅±10ppm,符合无线SoC对参考时钟精度的需求。
小尺寸：可以满足蓝牙模块对体积的要求,节约PCB面积。
高可靠性：符合RoHS标准且无铅,具备高可靠性。
抗干扰能力强：出色的抗EMI性能,是蓝牙,无线通信设备的最佳选择。
NX3225SA-26MHZ-STD-CQR-1作为一款小体积晶振,在极端恶劣的环境条件下也能具有稳定的启动特性,优异的抗环境性能,如耐热,振动和抗冲击性,回流温度分布（可用于无铅焊接）,符合AEC-Q200紧凑的表面安装晶体单元,该贴片晶振特别适用于汽车电子设备等应用,例如：汽车电子控制板,汽车动力转向控制器,汽车遥控器,汽车音影晶振,汽车胎压检测,通讯设备,无线网络,蓝牙模块,医疗设备,平板电脑等应用。
