| 型号 |
外部尺寸（mm） |
工作温度（℃） |
频率范围 |
PDF下载 |
| 1ZZCAA27120BB0A,27.12M晶振,10PF,15PPM,2016封装 |
2.0x1.6x0.65mm |
-40°C+85°C |
27.12MHz |
PDF下载 |
| 1ZZCAA26000AA0D,26MHz晶振,DSX211G,15PF,10PPM,KDS晶振 |
2.0x1.6x0.65mm |
-40°C+85°C |
26MHz |
PDF下载 |
| 16MHz晶振,2016封装,1ZZCAA16000BB0A,9PF,15PPM,DSX211G |
2.0x1.6x0.65mm |
-40°C+85°C |
16MHz |
PDF下载 |
| 26MHz晶振,DSX221G,8PF,7PPM,1ZNB26000LB0B,KDS晶振 |
2.5x2.0x0.75mm |
-40°C+85°C |
26MHz |
PDF下载 |
| 1ZNA16000BC0H晶振,16MHz晶振,2520,12PF,20PPM,DSX221G |
2.5x2.0x0.75mm |
-20°C+70°C |
16MHz |
PDF下载 |
| 16MHz晶振,DSX221G,9PF,20PPM,1ZNA16000AB0P |
2.5x2.0x0.75mm |
-20°C+75°C |
16MHz |
PDF下载 |
| 1ZCT08000EK0G,8M,8PF,50PPM,3225车规晶振 |
3.2x2.5x0.85mm |
-40°C+125°C |
8MHz |
PDF下载 |
| 16MHz晶振,DSX321G,8PF,50PPM,1ZCM16000EE0B |
3.2x2.5x0.85mm |
-40°C+85°C |
16MHz |
PDF下载 |
| 1ZCM08000EK0D,8MHz无人机晶振,DSX321G,8PF,100PPM |
3.2x2.5x0.85mm |
-40°C+85°C |
8MHz |
PDF下载 |
| 8MHz晶振,DSX321G,8PF,50PPM,1ZCM08000EE0A,KDS晶振 |
3.2×2.5×0.85mm |
-40°C+85°C |
8MHz |
PDF下载 |
| 40MHz晶振,DSX530GK晶振,1ZCG40000EK1B,8PF,50PPM |
5.0x3.2x1.0mm |
-40°C+85°C |
40MHz |
PDF下载 |
| 1ZCB26000LB0B,7PF,8PPM,DSX221G,26M晶振,KDS晶振 |
2.5x2.0x0.75mm |
-40°C+85°C |
26MHz |
PDF下载 |
| 26MHz晶振,2520封装,8PF,10PPM,1ZCB26000AA0L,DSX221G,KDS晶振 |
2.5x2.0x0.75mm |
-40°C+85°C |
26MHz |
PDF下载 |
| 38.4M晶振,2520晶振,10PF,10PPM,1ZCA38400AB0A,KDS晶振 |
2.5x2.0x0.75mm |
-40°C+85°C |
38.4MHz |
PDF下载 |
| 1ZCA26000CC0B,DSX221G,26M晶振,9PF,25PPM,KDS晶振 |
2.5x2.0x0.75mm |
-40°C+85°C |
26MHz |
PDF下载 |
| 32.768KHz晶振,1TJW125DJ4A723Q,12.5PF,20PPM,KDS晶振 |
8.0x3.8x2.4mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| 32.768KHz晶振,DMX-26S,12.5PF,10PPM,1TJS125BJ4A706Q,KDS晶振 |
8.0x3.8x2.4mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| DMX-26S,32.768KHz晶振,12.5PF,10PPM,1TJS125BJ4A421P,KDS晶振 |
8.0×3.8×2.4mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| 32.768KHz晶振,8038封装,6PF,20PPM,1TJS060DJ4A781Q |
8.0×3.8×2.4mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
| 32.768K晶振,1TJS060DJ4A770Q,DMX-26S,6PF,20PPM |
8.0x3.8x2.4mm |
-40°C+85°C |
32.768KHz |
PDF下载 |
